Note: Relay brand may vary from actual product as our stock rotates.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
This is a single channel relay board with one 24 volts high current relay. It is an ideal board to control & switch high current loads like a fan, lights, low power heater coils. It not only provides switching but also provides isolation between the power device and your micro-controller. Devices up to 5 Ampere can be switched using this relay.
This relay module has an onboard driver and a led to indicate the Relay Status (ON/OFF). Since this Relay board has an onboard driver transistor to provide the relay with the necessary holding and latching current these relays can work with any microcontroller, Arduino, Intel Edison Boards, Beagle-bone & Raspberry pi as well.. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
Note: Relay brand may vary from actual product as our stock rotates.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Maximum Load | AC 250V/10A, DC 30V/10A |
| Isolation | SMD Optocoupler, trigger current of only 5mA |
| Relay Power Supply | 5V, 9V, 12V, and 24V available |
| Trigger Select | High or low, set via jumper |
| Fault-Tolerant Design | Relay will maintain even if control line is broken |
| Indicators | Power (green) and relay status (red) |
| Size | 50mm x 26mm x 18.5mm |
| Mounting Holes | Four holes, 3.1mm in diameter, with a pitch of 44.5mm x 20.5mm |
| Input VCC | Relay power supply positive |
| Input GND | Relay power supply negative |
| Input IN | Signal trigger input for high or low level signal, select via jumper |
| Output NO | Relay normally open |
| Output COM | Relay common pin |
| Output NC | Relay normally closed |
| High Level Trigger | IN input high level signal, NO connects with COM; IN input low level signal, NC connects with COM |
| Low Level Trigger | IN input low level signal, NO connects with COM; IN input high level signal, NC connects with COM |
| Shipment Weight | 0.03 kg |
| Shipment Dimensions | 12cm x 8cm x 4cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 1 Channel 24V Relay Board Module with OPTO Isolation Support High or Low Level Trigger
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of 1 Channel 24V Relay Board Module with OPTO Isolation Support High or Low Level Trigger in Bangladesh is BDT 145 You can buy the 1 Channel 24V Relay Board Module with OPTO Isolation Support High or Low Level Trigger at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
