The ESP32-S3-EYE is a compact and powerful AI development board built for advanced image recognition and audio processing applications. Based on the robust ESP32-S3 SoC, it integrates an 8MB Flash and 8MB PSRAM memory setup, providing ample resources for complex AI computations and data handling.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
The ESP32-S3-EYE is a compact and powerful AI development board built for advanced image recognition and audio processing applications. Based on the robust ESP32-S3 SoC, it integrates an 8MB Flash and 8MB PSRAM memory setup, providing ample resources for complex AI computations and data handling.
Featuring a 2-megapixel camera, 1.3-inch LCD display, and microphone, this board is optimized for applications such as facial recognition, voice wake-up, smart surveillance, and IoT visual/audio interfaces. It supports Wi-Fi image transmission and Micro-USB debugging, making it highly versatile for developers looking to prototype AI-based smart devices.
Designed around ESP-WHO, Espressif’s AI development framework, the ESP32-S3-EYE offers extensive documentation and library support to simplify development and speed up deployment.
Powerful AI Capabilities: Built around the high-performance ESP32-S3 SoC
High-Quality Imaging: Equipped with a 2 Megapixel camera for clear and detailed image capture
Integrated Display: Features a 1.3-inch LCD screen for real-time monitoring and output display
Ample Memory: Includes 8MB Flash and 8MB Octal PSRAM for advanced processing and storage needs
Wi-Fi Image Transmission: Supports fast and reliable image streaming over Wi-Fi networks
Microphone Input: Enables audio capture for voice wake-up and audio processing applications
Micro-USB Debugging: Easy programming and debugging via Micro-USB connection
Comprehensive AI Development Support: Fully compatible with ESP-WHO AI development framework
Compact Design: Small form factor ideal for embedded smart devices
| Feature | Specification |
|---|---|
| Processor | ESP32-S3 SoC (dual-core) |
| Flash Memory | 8MB |
| PSRAM | 8MB (Octal) |
| Camera | 2 Megapixel |
| Display | 1.3 inch LCD screen |
| Wireless Connectivity | Wi-Fi 802.11b/g/n |
| Debugging Interface | Micro-USB port |
| Development Framework | ESP-WHO (Espressif AI Framework) |
| Storage Expansion | Onboard resources sufficient for AI applications |
| Supported Applications | Image recognition, audio processing, IoT vision systems |
Connect the ESP32-S3-EYE board to your computer via the Micro-USB port.
Follow the official Getting Started Guide:
ESP32-S3-EYE User Guide
Install the necessary development tools and SDKs (ESP-IDF with ESP-WHO libraries).
Start prototyping AI vision and voice projects such as facial recognition, motion detection, or voice-controlled devices.
Face recognition and security authentication
Voice wake-up and command recognition systems
Smart home vision/audio interfaces
IoT-enabled surveillance cameras
AI-powered robotic vision
Environmental monitoring using audio and visual sensors
1 x ESP32-S3-EYE Development Board
Compact yet powerful AI-capable platform with vision and voice processing
Fully supported by Espressif’s ESP-WHO framework for rapid AI development
Ideal for developers and researchers focusing on next-generation smart devices
Built-in Wi-Fi and Micro-USB ensure easy networking and debugging
Expand your AI development horizons with the advanced and compact ESP32-S3-EYE Development Board.
Order now and bring powerful image and audio recognition features to your next project!
The latest price of ESP32-S3-EYE Development Board in Bangladesh is BDT 9,950 You can buy the ESP32-S3-EYE Development Board at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
