FR4 Copper Clad Plate Laminate Single Side PCB is a glass fiber epoxy resin-based PCB with copper foil on one side.
The epoxy glass fiber forms the substrate on which the copper foil is hot pressed only on one side and the other side remains bare. It has a copper core for strength and the substrate acts as electrical insulation.
The PCB is ideal for prototyping and experimenting.
This PCB can almost be seen in electronic equipment like electronic watches, calculator, computers, communication electronic equipment, military weapon system, etc. As long as there are integrated circuits and other electronic devices, electrical interconnection between them will require the use of this type of PCB.
1. You may find some scratch marks due to handling and shipping. You need to clean the board using sandpaper with Acetone/Petrol/Nail Polish Remover.
2. The product dimensions may vary from the images.
Product Images are shown for illustrative purposes only and may differ from the actual product.
হ্যান্ডলিং এবং শিপিংয়ের কারণে আপনি কিছু স্ক্র্যাচ চিহ্ন খুঁজে পেতে পারেন। আপনাকে অ্যাসিটোন/পেট্রোল/নেলপলিশ রিমুভার দিয়ে শিরিষ কাগজ ব্যবহার করে বোর্ড পরিষ্কার করতে হবে।
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Material | Glass fiber epoxy reinforced copper core |
| Length (mm) | 200 |
| Width (mm) | 330 |
| Height (mm) | 0.8~0.9 |
| Weight (gm) | 219 |
| Shipment Weight | 0.225 kg |
| Shipment Dimensions | 22 × 33 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x FR4 Copper Clad Laminate Single Side PCB.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of FR4 Copper Clad Plate Laminate Single Side PCB - 0.8 mm thickness in Bangladesh is BDT 350 You can buy the FR4 Copper Clad Plate Laminate Single Side PCB - 0.8 mm thickness at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
