The power-management IC used on Raspberry Pi 5 integrates a real-time clock, and charging circuitry for a button cell which can power the clock while the main power is disconnected.
Raspberry Pi offers a Panasonic ML-2020 Lithium Manganese Dioxide battery, with a two-pin plug suitable for connection to the battery connector on the Raspberry Pi 5 PCB, and a double-sided adhesive pad to attach it to the inside of a case or another convenient location. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- Panasonic ML-2020 Battery
- Comes with a connector for Pi 5 board
- Easy to install and Replace
- Double-sided adhesive pad to attach it to the inside of a case
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
- Keeping track of the time even when your Raspberry Pi is turned off
- Logging data
- Scheduling tasks
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Battery Type |
Panasonic ML-2020 Lithium Manganese Dioxide |
| Voltage |
3V |
| Capacity |
45mAh |
| Connector Type |
Two-pin plug |
| Dimensions |
20mm x 20mm x 3mm |
| Shipment Weight |
0.55 kg |
| Shipment Dimensions |
10 × 9 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x Official Raspberry Pi 5 RTC Battery
