The Emax ECO II 2306 1700KV Brushless Motor is a high-efficiency power solution built for FPV racing drones, offering a perfect balance of performance, durability, and affordability. This motor represents the next evolution of the popular ECO line, redesigned with a robust, sleek profile and enhanced with N52 magnets to deliver superior throttle response and higher torque output.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
The Emax ECO II 2306 1700KV Brushless Motor is a high-efficiency power solution built for FPV racing drones, offering a perfect balance of performance, durability, and affordability. This motor represents the next evolution of the popular ECO line, redesigned with a robust, sleek profile and enhanced with N52 magnets to deliver superior throttle response and higher torque output.
With a rounded, reinforced bell design and a reflective finish, the ECO II not only performs under pressure but also looks the part in your high-speed builds. Whether you're building a long-range cruiser or a competitive racing drone, this motor delivers powerful and consistent performance.
Powerful N52 Magnets: Offers improved torque and RPMs over previous generation (N48)
Modern, Durable Design: Strengthened bell architecture with sleek reflective finish
Optimized for Performance: Tuned for better throttle response and racing-grade reliability
Budget-Friendly: Professional-level performance at a hobbyist-friendly price
| Specification | Detail |
|---|---|
| Motor Type | ECO II 2306 1700KV |
| KV Rating | 1700KV |
| Configuration | 12N14P |
| Voltage | 6S (25.2V) |
| Stator Size | 2306 |
| Magnets | N52 high-strength magnets |
| Prop Compatibility | DALPROP Cyclone 5040 |
| Mounting Pattern | Standard 16x16mm |
| Current (A) | Thrust (G) | Power (W) | Efficiency (G/W) | Speed (RPM) |
|---|---|---|---|---|
| 2.8 | 300 | 70.56 | 4.25 | 15,700 |
| 5.4 | 500 | 136.08 | 3.67 | 20,100 |
| 8.5 | 700 | 214.20 | 3.27 | 23,400 |
| 23.5 | 1500 | 592.20 | 2.53 | Max RPM |
FPV racing drones
Freestyle and long-range builds
DIY multirotor projects requiring efficient and powerful motors
Engineered for Racing: Delivers thrust, torque, and speed where it counts
Refined Design: Lightweight yet tough build for crash resistance
Outstanding Value: Premium performance at a fraction of the cost
Power up your drone with confidence and crush the competition with the Emax ECO II 2306 1700KV Brushless Motor.
Order now and experience the next level of FPV performance!
The latest price of Emax ECO II Series 2306 1700KV Brushless Motor for FPV Racing Drones in Bangladesh is BDT 2,950 You can buy the Emax ECO II Series 2306 1700KV Brushless Motor for FPV Racing Drones at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
