This potentiometer can be of Blue and White packaging or Black and Yellow package.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
The 10000-ohm Single-Turn Trimmer Potentiometer (103) offers smooth, precise resistance adjustment for various electronic applications. Designed with excellent linearity and secure long leads, it fits well into solderless breadboards and remains stable once inserted. This potentiometer has a typical resistance range of 9.5 to 10000 ohms, with a ±5% tolerance for accurate tuning. Its compact plastic package features a screwdriver adjustment on top for easy end-to-end single-turn control. Ideal for fine-tuning circuits, this cermet-type potentiometer is a valuable component for prototyping, educational projects, and other electronic tuning applications. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications | |
| Resistance | 10000 ohms (±5% tolerance) |
| Turns | 1 (Single-Turn) |
| Adjustment Type | Screwdriver (top-mounted) |
| Breadboard Compatibility | Yes |
| Package | Plastic, 3 radial leads |
| Wattage | 1/2W |
| Type | Cermet |
| Dimensions (L x W x H) | 7 x 7 x 5 mm (0.28 x 0.28 x 0.2 in) |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 3 x 3 x 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x Potentiometer 10k ohms Single-Turn Trimmer 103
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of Potentiometer 10 kohms Single-Turn Trimmer 103 in Bangladesh is BDT 10 You can buy the Potentiometer 10 kohms Single-Turn Trimmer 103 at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
