DC 3V-36V 15A Dual H-Bridge DC Motor Driver Robotics Bangladesh
  • DC 3V-36V 15A Dual H-Bridge DC Motor Driver Robotics Bangladesh
  • DC 3V-36V 15A Dual H-Bridge DC Motor Driver Robotics Bangladesh

DC 3V-36V 15A Dual H-Bridge DC Motor Driver

RBD-2308
  • DC 3V-36V 15A Dual H-Bridge DC Motor Driver for high-current applications
  • Can handle a maximum current of up to 30A for robust motor control
  • Features PWM modulation with 0%-99% duty cycle for precise motor speed control
  • Equipped with N-channel IRF3205 MOSFETs for enhanced performance and braking
  • Ideal for driving high-current brushed DC motors in robotics and other projects
BDT 1,650
rating Read the 2 reviews
Average rating: 5/5 Number of reviews: 2
Quantity
In-Stock

21 people have purchased this item recently
29 people added this item to the cart in last 10 days
7 items in stock in Uttara, Dhaka
  • Store Pickup Available! Store Pickup Available!
  • Free Ship Over 5000 BDT Free Ship Over 5000 BDT
  • Quality Product Quality Product
  • No Warranty No Warranty
  • No Replacement No Replacement

The DC 3V-36V 15A Dual H-Bridge DC Motor Driver is a high-efficiency solution for controlling two brushed DC motors simultaneously. Designed for demanding applications, this driver supports up to 30A maximum current and PWM modulation with a duty cycle range of 0%-99%. Utilizing IRF3205 MOSFETs, it ensures reliable motor acceleration and fast braking. Whether you're building battle robots, soccer robots, or high-power motor control systems, this driver delivers the performance and durability required for complex projects. Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Features:

  1. Dual H-Bridge Design: Controls two DC motors simultaneously with independent control.
  2. High Current Capability: Handles up to 30A maximum current for demanding applications.
  3. Wide Voltage Range: Operates at 3V-36V DC for compatibility with various power supplies.
  4. Precise Control: Supports PWM modulation with a 0%-99% duty cycle for speed and direction control.
  5. Advanced Braking: Fast motor braking capability for improved response and safety.
  6. Robust MOSFETs: Utilizes IRF3205 N-channel MOSFETs for efficient and reliable operation.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

  1. High-Power Robotics: Ideal for driving high-current brushed DC motors in battle and soccer robots.
  2. Motorized Vehicles: Suitable for electric scooters, small cars, or other motorized projects.
  3. Industrial Automation: Controls DC motors in automated systems requiring high performance.
  4. DIY Electronics: Perfect for hobbyists building robotic systems or motorized projects.
  5. Educational Kits: Used in teaching motor control concepts and robotics in academic settings.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

General Specifications
Voltage Range DC 3V-36V
Maximum Current 30A
Nominal Current 15A
PWM Duty Cycle Range 0%-99%
MOSFET Type IRF3205 N-channel
Motor Control Modes Forward, Reverse, Brake
Applications High-current DC motors, robotics, automation
Shipment Weight 0.0055 kg
Shipment Dimensions 10 x 6 x 3 cm

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

IRF3205 Motor Driver Setup

Package Includes:

1 x DC 3V-36V 15A Dual H-Bridge DC Motor Driver

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

What is the price of DC 3V-36V 15A Dual H-Bridge DC Motor Driver in Bangladesh?

The latest price of DC 3V-36V 15A Dual H-Bridge DC Motor Driver in Bangladesh is BDT 1,650 You can buy the DC 3V-36V 15A Dual H-Bridge DC Motor Driver at best price from our RoboticsBD or visit RoboticsBD Office.

Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product.

Product Images are shown for illustrative purposes only and may differ from the actual product.
Product Details
RBD-2308
7 Items
All product reviews are from verified purchases and are comply with DIRECTIVE (EU) 2019/2161
Dc driver
rating
Product is ok
H-bridges
rating
For anyone building robotics, automation systems, or high-power DC motor applications, finding a motor driver that can handle substantial current and a wide voltage range is crucial. This DC 3V-36V 15A Dual H-Bridge DC Motor Driver has exceeded my expectations, proving to be an incredibly robust and versatile solution for controlling two independent DC motors. The most impressive feature of this board is its current handling capability. With a continuous rating of 15A per channel (and often higher peak currents), it can effortlessly drive powerful motors that would quickly fry lesser drivers. This makes it ideal for larger robotic platforms, electric vehicle prototypes, or industrial automation where significant torque and speed are required. The wide input voltage range of 3V to 36V also provides immense flexibility, allowing it to be powered by various battery configurations or power supplies, from small 3.7V LiPos up to 24V or 36V systems. The dual H-bridge design is fantastic for controlling two motors independently, each with full forward and reverse capabilities. This is essential for differential drive robots or any system requiring precise control over two separate actuators. The board appears to use discrete MOSFETs, which are generally more robust and efficient than integrated H-bridge ICs for high-current applications, contributing to its impressive power handling. Integration with microcontrollers is straightforward. It typically requires a few GPIO pins per motor for direction and PWM (Pulse Width Modulation) speed control. The clear screw terminals for motor outputs and power input make wiring secure and reliable, minimizing the risk of loose connections or shorts. The board itself feels well-built, with proper heatsinking on the MOSFETs, which is vital for sustained high-current operation. The only issue with this board is the absence of heatsinks for the MOSFET arrays which could have enhanced its usability. I’ve used this driver in a few demanding projects, including a large robotic arm and a mobile platform, and it has performed flawlessly under various loads. It remains cool even during extended operation, indicating efficient power dissipation. For serious makers, roboticists, or engineers who need a dependable, high-power motor driver that won’t let them down, this 3V-36V 15A Dual H-Bridge is an excellent investment. It offers exceptional performance and reliability for its price.
