The 15mm Spring-Loaded Through Hole Inline Pogo Pin Header is designed for creating temporary but reliable electrical connections. With a standard 2.54mm spacing, this 10-pin pogo header is compatible with most PCBs, making it ideal for programming and testing jigs or JTAG connections. Its spring-loaded design ensures a stable connection, while the compact and robust build provides durability. Perfect for DIY projects, prototyping, and professional testing, this pogo pin header is a versatile tool for any electronics enthusiast. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications | |
| Type | Pogo Pin Header |
| Pin Spacing | 2.54mm (0.1") |
| Pin Count | 10 Pins |
| Total Length | 17.5mm |
| Spring-Loaded Length | 15mm |
| Material | Durable Metal |
| Customizable | Yes (can be cut/snapped) |
| Shipment Weight | 0.001kg |
| Shipment Dimensions | 2 x 2 x 2 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 15mm Spring Loaded Through Hole Inline Pogo Pin Header 2.54mm Spacing
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of 15mm Spring Loaded Through Hole Inline Pogo Pin Header 2.54mm Spacing in Bangladesh is BDT 230 You can buy the 15mm Spring Loaded Through Hole Inline Pogo Pin Header 2.54mm Spacing at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
