The 3mm(25GA) Hex coupling for Robot Smart Car Wheel 23mm Length is a compact coupling for joining your motor to the smart car wheel. They are mostly seen in smart cars, robotic vehicles or small robots. RoboticsBD
3mm(25GA) Hex Coupling is made from high-quality brass which allows you to connect the shaft of the motor and hub of the wheel. It equips hexagonal socket through which you can connect the hub of the wheel at one end of the coupling. The other hollow end of the coupling is connected to the motor shaft.
They have very simple structure and installation also doesn’t require any special skills. It requires no maintenance except tightening the screws when needed.
It safely transfers the rotating power of your motor shaft to the robotic vehicle wheel. The motors with hole diameter 3 mm and 4 mm are compatible with this 3mm(25GA) Hex coupling of 23mm length. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Note: The Package does not include any wheel, buy them separately on RoboticsBD
Click here Robot Smart Car Wheel
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Material | Brass |
| Inner Diameter (ID) (mm) | 3 |
| Outer Diameter (OD)(mm) | 11 |
| Size of Hex Socket | 14mm (Diagonal) |
| Length (mm) | 23 |
| Weight(gm) | 4.8 |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 3 × 2.5 × 2.5 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 3mm(25GA) Hex coupling 23mm long
The latest price of 3mm Copper Shaft Coupler 23mm length in Bangladesh is BDT 100 You can buy the 3mm Copper Shaft Coupler 23mm length at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
