The CH340 Isolated USB to TTL (Serial) Module is a high-reliability communication interface designed for environments where electrical isolation is critical. Featuring the trusted CH340 chip combined with optocoupler isolation, this module provides 1500V isolation voltage to safeguard against voltage surges, ground loops, and interference.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
The CH340 Isolated USB to TTL (Serial) Module is a high-reliability communication interface designed for environments where electrical isolation is critical. Featuring the trusted CH340 chip combined with optocoupler isolation, this module provides 1500V isolation voltage to safeguard against voltage surges, ground loops, and interference.
Capable of achieving communication speeds up to 921600bps, the module is ideal for debugging, programming, and serial communication tasks across a variety of embedded systems. Its USB-A connector, integrated isolated power supply, and plug-and-play compatibility with Windows, Linux, and MacOS make it a convenient, safe, and powerful tool for developers and engineers.
High-Speed Communication: Supports baud rates up to 921600bps
Complete Isolation: 1500V electrical isolation between USB and TTL interfaces
Versatile Power Options: Switchable between 5V and 3.3V levels
Integrated Isolated Power Supply: No external power needed
Optocoupler Protection: High-speed optocoupler ensures stable signal transmission with enhanced shock resistance
LED Indicators: Built-in LEDs for power, sending, and receiving status
USB Plug and Play: Supports Windows, Linux, and Mac 32/64-bit systems
Slotted PCB Design: Provides more than 3mm isolation distance for enhanced safety
Reverse Diode Protection: Safe for direct MCU programming
| Feature | Specification |
|---|---|
| Model | MCS-86C |
| Main Chip | CH340 |
| Isolation Voltage | 1500V |
| Communication Rate | Up to 921600bps |
| Input Voltage | 5V / 3.3V switchable |
| Current Output | Max 100mA |
| LED Indicators | Power, Sending, Receiving |
| Dimensions | 50mm x 24mm (65mm x 24mm with USB) |
| Operating Systems Supported | Windows / Linux / Mac (32/64-bit) |
Required for Normal Operation:
Level Selection Pin: Select 5V or 3.3V logic and power
TX: Serial data transmission (outgoing)
RX: Serial data receiving (incoming)
GND: Ground connection
Optional:
VCC: Power output (determined by selected voltage)
TX-D: Open-drain TX signal for MCU programming
5V/3.3V Outputs: Direct regulated voltage outputs from USB
50, 75, 100, 110, 134.5, 150, 300, 600, 900, 1200, 1800, 2400, 3600, 4800, 9600, 14400, 19200, 28800, 33600, 38400, 56000, 57600, 76800, 115200, 128000, 153600, 230400, 460800, 921600, 1500000, 2000000
DC Level Only: Supports TTL levels (5V/3.3V). Do not connect to RS-232 signal levels.
Default Setting: 3.3V logic level at factory.
Connection Note: TX and RX are directly connected by default for testing. Remove the short connection if necessary for your application.
Microcontroller programming and debugging
Safe serial communication with sensitive equipment
IoT and embedded system development
Field device maintenance where isolation is required
Robotics and automation systems
1 x CH340 Isolated USB to TTL (Serial) Module with USB-A Connector
Electrical protection ensures safe operation in high-interference environments
Flexible voltage compatibility for 3.3V and 5V systems
Reliable and easy to use with plug-and-play USB connection
Compact and durable design with built-in isolation for professional-grade applications
Protect your devices while maintaining fast, reliable communication with the CH340 Isolated USB to TTL (Serial) Module.
Order now and ensure your projects have the safe and stable serial interface they deserve!
The latest price of CH340 Isolated USB to TTL (Serial) Module with USB-A Connector MCS-86C in Bangladesh is BDT 1,250 You can buy the CH340 Isolated USB to TTL (Serial) Module with USB-A Connector MCS-86C at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
