General Specification |
Model |
UTi165H |
Sensor |
Uncooled focal plane |
Temperature range |
30˚C~45˚C |
Resolution |
0.1˚C |
Accuracy |
±0.5˚C @1m |
Minimum measuring distance |
15cm |
Temperature measurement response time |
≤500ms (95% of reading) |
Pixel of thermal imagery |
19200 (160×120) |
Pixel dimensions |
12μm |
Swatches |
Black white, red white, blue white iron red, rainbow, |
Bandwidth of infrared spectroscopy |
8~14μm |
Field of view (FOV) |
56°(H) × 42°(V) |
Instantaneous field of view (IFOV) |
6mrad |
Thermal imaging sensitivity |
<50mk |
Frame rate |
<9Hz |
Temperature display |
Center temperature measurement and high temperature tracking (default) |
Image format |
BMP |
Image modes |
Thermal imagery |
Temperature measuring point |
Besides central point, 3 temperature measuring points can be added |
Display resolution |
320×240 |
PC analysis software (PC) |
√ |
Data communication |
Type-C USB |
Auto power off |
Selectable (5min, 10min, 30min), 30min auto power off (default) |
Service time |
≧6 hours |
Charging time |
4 hours |
Image storage |
Micro SD card |
Power |
A single Li-ion 3.7V/5000mAh 26650 battery |
Display |
2.8" TFT LCD |
Product color |
Red & grey |
Product size |
236mm x 75.5mm x 86mm |
Standard accessories |
Manual, Type-C USB cable, 16GB TF card |
Standard carton gross weight |
2.2kg |
Shipment Weight |
2.200 kg |
Shipment Dimensions |
23.5 × 8.5 × 7.5 cm |
