The OMRON E3Z-D61 is a high-performance, compact diffuse-reflective photoelectric sensor engineered for reliable object detection across industrial automation, assembly lines, and smart systems. Utilizing an infrared LED light source and offering a sensing distance of 5mm to 100mm, this sensor provides precise, consistent detection, even in challenging environments.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
The OMRON E3Z-D61 is a high-performance, compact diffuse-reflective photoelectric sensor engineered for reliable object detection across industrial automation, assembly lines, and smart systems. Utilizing an infrared LED light source and offering a sensing distance of 5mm to 100mm, this sensor provides precise, consistent detection, even in challenging environments.
Designed for easy integration with a pre-wired 2-meter cable and equipped with NPN open collector output, the E3Z-D61 offers a versatile Light-ON/Dark-ON selectable mode. With features like surge suppression, reverse polarity protection, and short-circuit protection, it ensures safe and stable operation under a wide range of industrial conditions.
The E3Z-D61 meets international standards such as IP67 for water and dust protection and complies with EN60947-5-2 for both EMC and Low Voltage Directives, ensuring dependable operation in harsh environments.
Diffuse-reflective sensing method with adjustable sensitivity
Sensing distance: 5mm to 100mm (with white paper target 100x100mm)
Compact and durable housing with IP67 rating
Infrared LED light source (860nm wavelength)
Light-ON/Dark-ON mode selectable for flexible application
NPN open collector output with max load current of 100mA
Fast response time: 1ms maximum
Built-in protective circuits including surge suppression, short-circuit, and reverse polarity protection
Compliance with EMC and Low Voltage Directives
Operation and stability indicators for easy status monitoring
Pre-wired 2m cable for straightforward installation
Sensing Method: Diffuse-reflective
Sensing Distance: 5mm to 100mm
Light Source: Infrared LED (860nm)
Power Supply Voltage: 12V to 24V DC (-10% to +10%)
Current Consumption: 30mA DC max.
Output Type: NPN open collector
Load Current: 0 to 100mA
Residual Voltage:
≤1V (load current less than 10mA)
≤2V (load current 10mA to 100mA)
Operation Mode: Light-ON/Dark-ON selectable
Response Time: 1ms max.
Sensitivity Adjustment: Single-turn potentiometer
Protection Features:
Surge suppressor
Output short-circuit protection
Output and power supply reverse polarity protection
Insulation Resistance: 20MΩ min. at 500VDC
Dielectric Strength: 1000VAC, 50/60Hz for 1 minute
Degree of Protection: IP67 (IEC60529)
Standards Compliance:
EN60947-5-2 (Low Voltage, EMC)
EN55011 Group 1 Class A (Emission)
IEC61000-4-2/4-3/4-4 (Immunity)
Cable Length: 2 meters (pre-wired)
Indicators:
Orange: Operation indicator
Green: Stability indicator
Weight (packed): Approx. 65g
Tightening Torque: Max 0.5 N·m (M3 screws)
Mount the sensor securely using M3 screws, ensuring proper alignment with the detection target.
Connect the sensor to the power supply and control circuit via the pre-wired cable.
Set the desired mode (Light-ON or Dark-ON) according to your application needs.
Adjust the sensitivity using the single-turn potentiometer.
Monitor operation through the integrated LED indicators.
Conveyor and material handling systems
Automated production lines
Object and presence detection
Packaging machinery
Assembly robots
Smart warehouse systems
1 x OMRON E3Z-D61 Compact Photoelectric Sensor (Pre-wired 2m cable)
1 x Instruction Manual
Fast and reliable object detection with excellent sensing distance
Compact, IP67-rated design for harsh environments
Easy installation with pre-wired cable and adjustable sensitivity
Strong protection and compliance with international standards
Flexible operation for diverse industrial automation applications
Enhance your automation system with precision and reliability using the OMRON E3Z-D61 Compact Photoelectric Sensor.
Order now and experience industry-leading detection performance!
The latest price of OMRON E3Z-D61 Compact Photoelectric Sensor in Bangladesh is BDT 1,550 You can buy the OMRON E3Z-D61 Compact Photoelectric Sensor at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
