Product Description (180º Version):

The SERVO TD-8135MG 180º Digital Servo is a high-torque, waterproof servo designed for precision and durability in RC cars, robotic models, and DIY projects. Equipped with strong metal gears, a CNC aluminum middle shell, and a high-performance carbon brush motor, this servo ensures reliable performance in challenging environments. With a peak stall torque of up to 35.2kg.cm, it offers excellent power for heavy-duty applications. Its 180º rotation range and digital controller provide accurate and smooth control, making it ideal for a wide variety of uses.

Features:

1. High Torque Performance:

   • Delivers peak stall torque of up to 35.2kg.cm (at 8.4V), ideal for demanding applications.

2. Precision Rotation:

   • Offers a 180º ±3º rotation range, ensuring smooth and accurate movements.

3. Durable Construction:

   • Reinforced metal gears and CNC aluminum middle shell for wear resistance and a longer service life.

4. Waterproof Design:

   • Splash-resistant, suitable for use in outdoor and challenging environments.

5. Fast and Efficient:

   • High rotation speed with 0.22 sec/60° at 8.4V ensures responsive control.

6. Wide Compatibility:

   • Operates on a voltage range of 4.8V-7.2V, making it compatible with various RC models and robotic projects.

Specifications (180º Version):

• Torque:
  • 32.7kg.cm (4.8V)
  • 35.2kg.cm (8.4V)
• Operating Voltage: 4.8V - 8.4V
• No-Load Speed:
  • 0.32 sec/60° (4.8V)
  • 0.22 sec/60° (8.4V)
• Current:
  • Running: 40mA (4.8V), 200mA (8.4V)
  • Stall: 2800mA ±10% (4.8V), 3800mA ±10% (8.4V)
• Rotation Angle: 180º ±3º
• Size: 40 x 20.5 x 40.5mm
• Weight: 56g ±5%
• Gear Material: 5 Metal Gears
• Control Signal: Pulse Width Modification (PWM)
• Connector Wire Length: 320mm ±5mm
• Waterproof: Yes

How to Use (180º Version):

1. Connect to Power Source:

   • Use a 4.8V-7.2V power supply for operation.

2. Wiring:

   • Connect the servo wires to your controller:
     • Red: Power (+)
     • Black: Ground (-)
     • Yellow/White: Signal (PWM)

3. Programming:

   • Configure your microcontroller to send PWM signals within the range of 500–2500µsec to control the servo's position.

4. Installation:

   • Mount the servo securely in your RC car, robot, or project.

5. Operation:

   • Test the servo's range and responsiveness, adjusting as necessary for your specific application.

Applications (180º Version):

1. RC Cars and Boats:

   • Ideal for steering, suspension, and other high-torque tasks.

2. Robotics:

   • Use in robotic arms, joints, and other precision movement applications.

3. DIY Projects:

   • Perfect for Arduino and Raspberry Pi-controlled automation.

4. Heavy-Duty Systems:

   • Suitable for lifting or rotating systems in machinery or hobbyist projects.

What is the price of TD-8135MG Digital High Torque Servo Motor Metal Gear 35kg 180º in Bangladesh?

The latest price of TD-8135MG Digital High Torque Servo Motor Metal Gear 35kg 180º in Bangladesh is BDT 2,200 You can buy the TD-8135MG Digital High Torque Servo Motor Metal Gear 35kg 180º at best price from our RoboticsBD or visit RoboticsBD Office.
