1.5V USB ultrasonic mist maker driver board and atomizer plate.
2. Low driving voltage, low power, low impedance, stable waveform, high conversion efficiency.
3. Round ring atomizer plate, middle spray, 5um ultra-fine spray aperture, 740 ultra-dense spray holes.
4. The surface of the atomizing sheet adopts an oxidation-resistant silver layer to protect the coating process and long life.
5. Noiseless and make mist for the whole night, provide continuous moisture, and relax your mood.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
Features:
1.5V USB ultrasonic mist maker driver board and atomizer plate.
2. Low driving voltage, low power, low impedance, stable waveform, high conversion efficiency.
3. Round ring atomizer plate, middle spray, 5um ultra-fine spray aperture, 740 ultra-dense spray holes.
4. The surface of the atomizing sheet adopts an oxidation-resistant silver layer to protect the coating process and long life.
5. Noiseless and make mist for the whole night, provide continuous moisture, and relax your mood.
Product introduction:
Circuit board parameters:
Circuit board product voltage: DV 5V
Current: 300mA
Power: 2W
Frequency: 108KHz, fixed frequency single-chip microcomputer
Driver board size: length 35×width 20×height 17mm (there will be slight errors)
Strong versatility, a large amount of fog, stable performance, the chip has an automatic timing shutdown function (4 hours of continuous work will automatically shut down protection if you need to turn it on again, press the power on again). 5V USB power supply mode can be powered by a MICRO charging cable.
Atomizing film parameters:
The net diameter of the atomized steel sheet is 16mm, the outer diameter of the silicone ring is 20mm, and the wire length is 8cm.
Product voltage DV 5V, current 300mA, power 2W, frequency 108KHz, hole number 740, hole diameter 5um.
The microporous atomized sheet produced by us is coated with a special glaze protective layer on the surface of the ceramic sheet, which is resistant to acid and alkali and prevents the silver layer from being corroded and oxidized by the liquid.
The latest price of USB Mini Humidifier Mist Maker And Driver Circuit Board DIY Kits in Bangladesh is BDT 380 You can buy the USB Mini Humidifier Mist Maker And Driver Circuit Board DIY Kits at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
