The 6 Pin JST-PH Male Right Angle Connector with a 2.00mm pitch is an essential component for electronic projects requiring compact and reliable connections. This male connector is designed for use in space-constrained applications such as mobile phones, tablets, and other portable devices, where saving space without compromising performance is crucial. The polarized design ensures that connections are made correctly, reducing the risk of reversed wiring. It features a standard 2.00mm pitch and can be easily soldered onto your circuit boards, making it a versatile choice for a variety of projects. With a current rating of 3A and a voltage rating of 250V, this connector is well-suited for a wide range of applications. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications | |
| Connector Type | Header |
| Contact Type | Male Pin |
| Number of Positions | 6 |
| Number of Rows | 1 |
| Pitch | 2.00mm |
| Current Rating | 3A |
| Voltage Rating | 250V |
| Operating Temperature | -25°C to 85°C |
| Mounting Type | Through Hole |
| Weight | 0.005 kg |
| Shipment Dimensions | 3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 6 Pin JST-PH Male Right Angle Connector 2.00mm Pitch
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of 6 Pin JST-PH Male Right Angle Connector 2.00mm Pitch in Bangladesh is BDT 30 You can buy the 6 Pin JST-PH Male Right Angle Connector 2.00mm Pitch at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
