The Mars S Smart Rover Control Board is a versatile, open-source microcontroller board designed for robotics and smart rover projects. Built around the reliable ATmega328P chip, this board supports both Arduino IDE and Mixly graphical programming, making it perfect for beginners, students, and developers alike.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
The Mars S Smart Rover Control Board is a versatile, open-source microcontroller board designed for robotics and smart rover projects. Built around the reliable ATmega328P chip, this board supports both Arduino IDE and Mixly graphical programming, making it perfect for beginners, students, and developers alike.
The 2019 upgrade improves upon the 2016 version by enhancing USB stability, improving motor control interfaces, and resolving buzzer heating issues. It integrates key components like a 5V 1.5A power conversion IC, onboard buzzer, voltage detection, and dual-channel DC motor drivers—allowing you to control two motors without additional drivers.
Key Features:
Based on ATmega328P microcontroller
Fully compatible with Arduino IDE and Mixly graphical programming
Onboard dual DC motor control (2 channels, 1.2A each)
USB-to-Serial interface for easy programming
Integrated 5V 1.5A power conversion IC
Onboard buzzer and voltage detection
Compact design with dedicated fixing holes for smart rover chassis
Ideal for smart robots, autonomous vehicles, and educational kits
Technical Specifications:
Microcontroller: ATmega328P
Flash Memory: 32KB
SRAM: 2KB
PWM Outputs: 6
Analog Inputs: 8
Digital I/O Ports: 24
Communication Ports: 1 UART, 1 I2C, 1 ISP
Operating Voltage (VCC): 6–12V DC
5V Output Current: Up to 1.5A
DC Motor Drive Output: 2 channels at 1.2A each
No-load Current: 18mA
Board Dimensions: 65mm × 50mm × 13mm max height
Mounting Hole Diameter: 3mm
How to Use:
Connect to your PC via USB for programming using Arduino IDE or Mixly.
Power the board via DC socket (6–12V).
Connect DC motors to the motor terminals to control directly via the board.
Use the I/O ports to interface with sensors, LEDs, and other modules.
Utilize built-in buzzer and voltage detection for interactive feedback and monitoring.
Applications:
Smart rover and robotic vehicle platforms
Educational electronics and coding kits
DIY automation systems
Arduino-based prototype development
IoT hardware control boards
Package Includes:
1 × Mars S Smart rover Control Board
Why Choose This Product?
The Mars S Control Board offers a powerful blend of motor control, sensor integration, and development flexibility in a compact, beginner-friendly package. With full support for graphical and text-based programming, it’s an excellent tool for turning your robotics ideas into reality.
Start building smarter robots today with the Mars S Smart Rover Control Board – where reliable hardware meets versatile development!
The latest price of Mars S Smart Rover Control Board Arduino ATmega328P in Bangladesh is BDT 2,890 You can buy the Mars S Smart Rover Control Board Arduino ATmega328P at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
