The 7400 NAND Gate is a digital logic gate that implements the NAND (Not-And) function. It has two or more inputs and one output. The output is "low" (0) only when all inputs are "high" (1), otherwise the output is "high" (1). The 7400 NAND Gate is widely used in digital circuits and logic systems due to its versatility and ease of use. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Digital Logic Circuits: The 7400 NAND Gate is widely used in digital logic circuits as a basic building block for combinatorial logic. It can be used to implement various logic functions such as NOT, AND, OR, etc.
Flip-Flops: The 7400 NAND Gate can be used to construct various types of flip-flops such as SR, JK, D, T, etc., which are commonly used in digital systems to store and transfer binary information.
Counters: The 7400 NAND Gate can be used to construct various types of counters such as binary, decimal, up/down, etc., which are commonly used in digital systems to keep track of the number of events that have occurred.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Mounting Type | Through Hole |
| Product Series | DM7400 |
| Weight (gm) | 1 (approx.) |
| Shipment Weight | 0.01 kg |
| Shipment Dimensions | 3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 7400 NAND Gate
The latest price of 7400 NAND Gate in Bangladesh is BDT 20 You can buy the 7400 NAND Gate at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
