LM324N is a quad operational amplifier (Op-Amp) integrated circuit. It contains four independent, high-gain, frequency-compensated operational amplifiers. The LM324N is capable of operating over a wide range of voltages, making it suitable for use in a variety of applications. It is used in many circuits such as comparators, buffer amplifiers, voltage regulators, and converters. The LM324N is designed for use in low-power applications, where it provides low input bias current, low offset voltage, and high input impedance. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
Note: Supply voltages larger than 32V for single supply and outside the range of ±16V for dual supply can permanently damage the IC
Warnings: This device has limited built-in ESD protection. The leads should be shorted together or device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Package/Case | PDIP-14 |
| Amplifier Type | General Purpose Amplifier |
| Minimum Supply Voltage (V) | 3 |
| Maximum Supply Voltage (V) | 32 |
| Number of Channel | 4 |
| Output Current Per Channel | 40 mA |
| Input Bias Current (Ib) | 45 nA |
| Gain Bandwidth Product (GBP) | 1.2 MHz |
| Input Offset Voltage (Vos) | 7 mV |
| Slew Rate (SR) | 0.5 V/us |
| CMRR (dB) | 65 ~ 80 |
| Voltage Gain (dB) | 100 |
| Technology | Bipolar |
| Max Dual Supply Voltage | ±16 V |
| Min Dual Supply Voltage (V) | ± 1.5 |
| Max. Operating Current (mA) | 1.5 |
| Operating Temperature Range (°C) | 0 to 70 |
| Dimensions (mm) LxWxH | 19.3 x 6.35 x 4.47 |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x LM324N Quad Op-Amp
The latest price of LM324N Quad Op-Amp in Bangladesh is BDT 25 You can buy the LM324N Quad Op-Amp at best price from our RoboticsBD or visit RoboticsBD Office.
|
