The most commonly used op-amp is IC741. The 741 op-amp is a voltage amplifier, it inverts the input voltage at the output, can be found almost everywhere in electronic circuits.
The LM741 series are general purpose operational amplifiers which feature improved performance over industry standards like the LM709. They are direct, plug-in replacements for the 709C, LM201, MC1439, and 748 in most applications. The amplifiers offer many features which make their application nearly foolproof: overload protection on the input and output, no latch-up when the common-mode range is exceeded, as well as freedom from oscillators. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Package/Case | PDIP-8 |
| Mounting Type | Through Hole |
| Amplifier Type | General Purpose Amplifier |
| Number of Channel | 1 |
| Output Current Per Channel | 25 mA |
| Input Bias Current (Ib) | 0.5 uA |
| Gain Bandwidth Product (GBP) | 1 MHz |
| Input Offset Voltage (Vos) | 6 mV |
| Slew Rate (SR) | 0.5 V/us |
| CMRR (dB) | 70 |
| Voltage Gain (dB) | 106.02 |
| Technology | Bipolar |
| Max Dual Supply Voltage | ±18 V |
| Min Dual Supply Voltage (V) | ± 5 |
| Max. Operating Current (mA) | 2.8 |
| Operating Temperature Range (°C) | 0 to 70 |
| Dimensions (mm) LxWxH | 9.27 x 6.35 x 3.3 |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 3 × 3 × 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x IC 741 Operational Amplifier
The latest price of IC 741 Operational Amplifier in Bangladesh is BDT 20 You can buy the IC 741 Operational Amplifier at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
