This black, latching (self-locking) push button switch offers a reliable and secure way to control various electronic applications. Unlike momentary buttons, this switch remains locked in the "on" position after a single press and requires another press to turn "off." The compact size (1.06" overall length) makes it ideal for space-constrained environments, while the metal construction ensures durability. This versatile switch features easy panel mounting with a 7mm threaded body and offers reliable performance with a 0.5A and 250VAC rating. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- Latching Action: Single press turns "on," another press turns "off" - ideal for maintaining state.
- Compact Design: Small footprint (11mm depth) fits in tight spaces.
- Easy Installation: Thread mounting for secure panel integration.
- Durable Metal Construction: Ensures long-lasting performance.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Applications:
- Industrial Controls: Maintain control over machinery or processes.
- Robotics Projects: Implement locking control functions for robots.
- DIY Electronics: Integrate secure On/Off functionality into various projects.
- Security Systems: Activate alarms or control access points.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Action Type |
Latching (Self-Locking) |
| Material |
Plastic cap, Metal body |
| Color |
Black |
| Poles |
SPST |
| Rating Voltage DC |
50V / 0.3A |
| Rating Voltage AC |
220V / 1A |
| Terminals |
2 Pins |
| Mounting Thread Dia. |
7mm |
| Button Dia. |
6mm |
| Terminals Pitch |
3mm |
| Overall Size |
27x11mm |
| Weight |
4g |
| Shipment Weight |
0.005 kg |
| Shipment Dimensions |
12 x 8 x 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Documentation:
- For proper operation, follow the recommended voltage and current ratings.
- Installation should only be performed by qualified individuals familiar with electrical safety.
- Keep out of reach of children.
- Dispose of according to local electronic waste regulations.
Package Includes:
1 x 7mm Thread 2 Pin Metal Self-Locking Switch - Black
