This red, latching (self-locking) push button switch offers a reliable and secure way to control various electronic applications. Unlike momentary buttons, this switch remains locked in the "on" position after a single press and requires another press to turn "off." The compact size (1.06" overall length) makes it ideal for space-constrained environments, while the metal construction ensures durability. This versatile switch features easy panel mounting with a 7mm threaded body and offers reliable performance with a 0.5A and 250VAC rating. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Action Type | Latching (Self-Locking) |
| Material | Plastic cap, Metal body |
| Color | Red |
| Poles | SPST |
| Rating Voltage DC | 50V / 0.3A |
| Rating Voltage AC | 220V / 1A |
| Terminals | 2 Pins |
| Mounting Thread Dia. | 7mm |
| Button Dia. | 6mm |
| Terminals Pitch | 3mm |
| Overall Size | 27x11mm |
| Weight | 4g |
| Shipment Weight | 0.005 kg |
| Shipment Dimensions | 12 x 8 x 3 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 7mm Thread 2 Pin Metal Self-Locking Switch - Red
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of 7mm Thread 2 Pin Metal Self-Locking Switch - Red in Bangladesh is BDT 55 You can buy the 7mm Thread 2 Pin Metal Self-Locking Switch - Red at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
