ESP32-WROVER-E Chipset | Wi-Fi/BLE Connectivity | Industrial IoT Solutions
The USR-EG118 IoT Gateway is a powerful and versatile ESP32-based gateway designed for Industrial IoT applications. Featuring an Xtensa® 32-bit LX6 dual-core MCU running at 240 MHz, 4MB PSRAM, and up to 8MB SPI flash memory, it offers wireless and wired communication capabilities to seamlessly integrate with cloud platforms and industrial automation systems.
With RS485/RS232, Ethernet, Wi-Fi (802.11b/g/n), BLE 4.2, and multiple I/O interfaces, this IoT gateway enables reliable data transmission, remote monitoring, and real-time device control. It supports Arduino IDE and ESP-IDF, making development easier and faster for IoT enthusiasts, engineers, and professionals.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
ESP32-WROVER-E Chipset | Wi-Fi/BLE Connectivity | Industrial IoT Solutions
The USR-EG118 IoT Gateway is a powerful and versatile ESP32-based gateway designed for Industrial IoT applications. Featuring an Xtensa® 32-bit LX6 dual-core MCU running at 240 MHz, 4MB PSRAM, and up to 8MB SPI flash memory, it offers wireless and wired communication capabilities to seamlessly integrate with cloud platforms and industrial automation systems.
With RS485/RS232, Ethernet, Wi-Fi (802.11b/g/n), BLE 4.2, and multiple I/O interfaces, this IoT gateway enables reliable data transmission, remote monitoring, and real-time device control. It supports Arduino IDE and ESP-IDF, making development easier and faster for IoT enthusiasts, engineers, and professionals.
✅ High-Performance ESP32-WROVER-E – Dual-core Xtensa® 32-bit LX6 MCU with 240 MHz processing speed for efficient performance.
✅ Multiple Communication Interfaces – Includes 1x RS485/RS232, 2x Digital Output (DO), 1x Digital Input (DI), 1x Analog Input (AI), and 1x RJ45 Ethernet port.
✅ Advanced Wireless Connectivity – Supports Wi-Fi 802.11b/g/n (up to 150Mbps) and BLE 4.2 with transmitting power up to 20.5 dBm.
✅ Flexible Networking Methods – AP, STA, AP+STA, AP+LAN, AP+WAN, allowing versatile communication between serial devices, LAN devices, and cloud servers.
✅ Cloud Integration Support – Compatible with AWS IoT, enabling real-time data monitoring and cloud-based applications.
✅ Open Source & Easy Development – Supports Arduino IDE and ESP-IDF for seamless development with C-based SDK.
✅ Industrial-Grade Design – Wall and DIN rail mounting options for secure installation in industrial environments.
✅ Chipset: ESP32-WROVER-E
✅ Processor: Xtensa® 32-bit LX6 Dual-Core MCU
✅ Clock Speed: 240 MHz
✅ Flash Memory: Up to 8MB SPI Flash
✅ RAM: 4MB PSRAM
✅ Serial Port: 1 x RS485/RS232
✅ I/O Ports: 2 x DO, 1 x DI, 1 x AI
✅ Ethernet: 1 x RJ45
✅ Wi-Fi: 802.11 b/g/n, up to 150Mbps, RF: 2412~2484MHz, Tx Power: up to 20.5 dBm
✅ Bluetooth: BLE 4.2
✅ Supported Configurations: AP, STA, AP+STA, AP+LAN, AP+WAN
✅ Cloud Connectivity: AWS IoT Platform Support
✅ Development Platforms: Arduino IDE, ESP-IDF
✅ Programming Language: C
✅ Mounting Options: Wall & DIN Rail
✅ Power Input: 5V/9V/12V/24V DC (optional, depending on configuration)
This Arduino Open Source IoT Gateway is ideal for applications requiring remote monitoring, automation, and control of industrial systems.
✅ Wastewater Treatment – Monitor and control water treatment systems remotely.
✅ Agricultural Irrigation – Automate smart irrigation systems for optimized water usage.
✅ Solar Energy Monitoring – Integrate with solar power systems to track and analyze energy production.
✅ Smart Farming – Real-time monitoring of livestock, temperature, and humidity levels.
✅ Industrial Automation – Seamless integration with PLC systems, sensors, and actuators for industrial control.
✅ IoT Prototyping & Development – Perfect for makers, engineers, and developers exploring IoT solutions.
✅ High Performance ESP32-WROVER-E Chipset – Delivers efficient processing for IoT applications.
✅ Versatile Communication Interfaces – Supports RS485, RS232, Ethernet, Wi-Fi, and BLE for seamless connectivity.
✅ Supports Cloud-Based Monitoring – Compatible with AWS IoT for real-time data logging and analytics.
✅ Industrial-Grade Durability – Designed for harsh environments, ensuring long-term stability.
✅ Easy to Develop & Integrate – Supports Arduino IDE and ESP-IDF, making development hassle-free.
✅ Flexible Mounting Options – Wall and DIN rail mounting for secure and convenient installation.
Enhance your industrial automation, smart agriculture, and IoT projects with the USR-EG118 Open Source IoT Gateway.
Buy Now & Start Building Your Next IoT Solution!
The latest price of Arduino PLC IoT Gateway USR-EG118 in Bangladesh is BDT 12,850 You can buy the Arduino PLC IoT Gateway USR-EG118 at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
