Emax SimonK Series Multirotor 30A Brushless ESC

RBD-1691
  • Model: Emax SimonK Series.
  • LiPo Battery Input: 2 ~ 3S.
  • Continuous Current: 30A.
  • Burst Current(10S): 40A (for 10Sec).
  • BEC Mode: Linear.
  • BEC Output: 1A/5V.
BDT 1,190
rating Read the review
Average rating: 5/5 - Number of reviews: 1
Quantity
Out-of-Stock

18 people have purchased this item in last 12 months
10 people recently added this item to the cart
There are not enough products in stock
notifications Notify Me
  • Store Pickup Available! Store Pickup Available!
  • Free Ship Over 5000 BDT Free Ship Over 5000 BDT
  • Quality Product Quality Product
  • No Warranty No Warranty
  • No Replacement No Replacement

Emax SimonK Series Multirotor 30A Brushless ESC (Original) is a brushless dc motor speed controller. The low output resistance greatly enhances power stability, and this will improve the great battery life. Emax SimonK Series Multirotor 30A Brushless ESC is programmed to start the brushless dc motor. This ESC has a greater current handling capacity which is 30A continuous and the peak current is 40A for the last 10 seconds only. RoboticsBD

Features :

  1. Based on SimonK firmware, further optimized to the perfect drive performance.
  2. Low-voltage protection, over-heat protection, and throttle signal loss protection.
  3. Separate power supply for MCU and BEC, enhancing the ESC’s ability to eliminate magnetic interference.
  4. Parameters of the ESC can be set via a program card or transmitter.
  5. Throttle range can be set to be compatible with different receivers.
  6. Equipped with built-in linear BEC or switch BEC.
  7. Max speed: 210,000 rpm for 2-pole, 70,000 rpm for 6-pole, 35,000 rpm for 12-pole.

General Specification
Model Emax SimonK Series 30A
Burst Current (A) 40
Constant Current (A) 30
BEC Yes (5V/2A)
Suitable Lipo Batteries 2 ~ 3S
Color Black and Red
Dimensions (mm) LxWxH 52 x 26 x 7
Weight (gm) 28
Application BLDC Motors, Multirotors, Rc Planes etc.
Shipment Weight 0.03 kg
Shipment Dimensions 6 × 3 × 1 cm

Package Includes :

1x Emax SimonK Series Multirotor 30A Brushless ESC module.

What is the price of Emax SimonK Series Multirotor 30A Brushless ESC in Bangladesh?

The latest price of Emax SimonK Series Multirotor 30A Brushless ESC in Bangladesh is BDT 1,190 You can buy the Emax SimonK Series Multirotor 30A Brushless ESC at best price from our RoboticsBD or visit RoboticsBD Office.

Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product.

Product Images are shown for illustrative purposes only and may differ from the actual product.

Product Details
RBD-1691
Very Good Product.
rating
03/10/2022
Saravanan Veerayah Jayaraman
Reliable ESC BEC
