A relay is an electrically operated switch. It consists of a set of input terminals for a single or multiple control signals, and a set of operating contact terminals. The switch may have any number of contacts in multiple contact forms, such as make contacts, break contacts, or combinations thereof. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- Terminal Type: PCB
- Contact Load: High Power
- Contact Ratings: 1A,1C
- Contact Resistance: 100mΩ(at 10A 5VDC)
- Contact Material: Silver Alloy
- Size: Miniature
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Operating Voltage (VDC) |
24 |
| Rated load: |
10A 250VAC/28VDC |
| Coil resistance: |
70 ohms |
| Coil rated voltage: |
45% ~ 85% |
| Storage condition (℃) |
3-48VDC |
| Coil pick-up voltage: |
5 VDC |
| Coil Current: |
71-90mA |
| Coil power: |
0.36W, 0.45W |
| Weight (gm) |
50 |
| Shipment Weight |
0.0251 kg |
| Shipment Dimensions |
2 × 2 × 2 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x Songle Power 24VDC Relay SRU-12VDC-SL-C PCB 5 Pin.
