Reference: RBD-0492

Omron Proximity Sensor Switch E2E-X5MF2-Z

1 review

Proximity-sensing / Diffuse Type Voltage: DC 6-36V Current: 300mA Sensory Distance: 5mm

Reference: RBD-1192

Hall Effect Sensor 6851/A3144

8 reviews

Digital Output Hall-effect sensor. Operating voltage: typically 5V. Output Current: 25mA. It can be used to detect both the poles of a magnet.

Reference: RBD-0822

Hall Effect Sensor Switch Magnetic Detector Module For Arduino

8 reviews

S49E hall sensor Features wide-range voltage comparator LM393 Signal output indicator Analog / Digital output

Reference: RBD-1401

Festo SMT-10M-PS-24V-E-0,3-L-M8D

Measured variable Position Measuring principle Magneto-resistive Ambient temperature -40 °C ... 70 °C Repetition accuracy 0.2 mm Switching output PNP Switching element function N/O contact On time ≤1.3 ms Switch-off time ≤1.4 ms Max. switching frequency 150 Hz Max. output current 100 mA Max. output current in mounting kits 50 mA Max. switching capacity DC...

Reference: RBD-0816

VL6180 VL6180X ToF Range Finder Sensor

1 review

Power Supply Voltage: 3.3V~5V Operating Current: ＜5mA Measuring Distance: 5-100mm VCSEL light source Strong anti-interference Based on DFrobot Fermion VL6180X ToF Distance Ranging Sensor (Breakout)

Reference: RBD-2507

GY-US42 V2 i2c Pixhawk APM Flight Control Ultrasonic Distance Measurement Module

Operating voltage: 3~5 V Resolution: 1cm Response frequency: 15 HZ (full range) Operating current: 9mA (vcc = 5v) Operating temperature: -20℃ -65℃ Storage temperature: -40℃ -85℃ Measurement range: 20cm ~ 720cm (vcc = 5v) Package Included: 1Pc GY-US42 Ultrasonic Distance Measuring Module

Reference: RBD-0396

Ultrasonic Transducer Waterproof Distance Measuring Sensor Module

13 reviews

Integrated with wire enclosed waterproof probe, suitable for wet, harsh measurement occasions Small size, easy to use Operating Voltage: 5 V Sonar Sensing Range: 25-450 cm Max. Sensing Range: 450 cm Frequency: 40 KHz. RoboticsBD

Reference: RBD-2781

M03 Non-Contact Liquid Level Detection Module Sensor

1 review

The M03 Non-Contact Liquid Level Detection Module Sensor offers reliable liquid level sensing without direct contact, ensuring convenience and accuracy in various applications. Designed for durability and refined performance, this module extends service life while providing accurate liquid level detection.Power supply voltage range of 3.3-5V

Reference: RBD-2780

M04 Non-Contact Liquid Level Detection Module Sensor

1 review

The M04 Non-Contact Liquid Level Detection Module Sensor offers reliable liquid level sensing without direct contact, ensuring convenience and accuracy in various applications. Designed for durability and refined performance, this module extends service life while providing accurate liquid level detection.M04 supports a wider range of 3.3-24V (Should Not...

Reference: RBD-2215

4 Channel Infrared Line Following and Obstacle Sensor

1 review

Working voltage (V): 3.3 ~ 5 Working current (A): Above 1A Operating Temperature (℃): -10 ~ +50 Mounting hole: M3 Detection range: 1mm ~ 60 cm adjustable.

Reference: RBD-3315

US-100 Ultrasonic Range Finder Module

1 review

The US-100 Ultrasonic Range Finder Module uses sound waves to both detect the presence of and measure the distance to objects in front of it at distances of up to 15 feet.  It uses an easy to use serial interface.

Reference: RBD-2661

IR Beam Interruption Sensor - LED 3mm - 0-50 cm

1 review

The sensor reacts to an interruption in the beam of infrared light that is transmitted between the transmitter and receiver. When the beam is interrupted by another object, the receiver signals this event by lighting up. The module is equipped with a 3 mm IR LED with an illumination angle of 10°. Beam interruption systems are used e.g. in measuring gates.

Reference: RBD-3520

CJMCU-88 TMD27713 IRLED + ALS + Proximity Sensor

The CJMCU-88 TMD27713 sensor module combines infrared (IR) proximity detection, ambient light sensing (ALS), and a built-in IR LED driver into a single, compact solution. Ideal for modern smart devices, this all-in-one sensor delivers high precision and reliability across a wide range of lighting environments—from full sunlight to total darkness.

Reference: RBD-1677

52mm PP Liquid Water Level Sensor Horizontal Float Switch Down

Contact Rating: 10 W. Switching Voltage: 220 V. Switching Current: 0.5 A. Breakdown Voltage: 220 VDC. Carry Current: 1 A. Contact Resistance: 100 mΩ.

Reference: RBD-2790

Hall-Effect Sensor - US1881 (Latching)

The US1881 is an integrated Hall-Effect latched sensor. That's nice but what does it do? Holding a magnet near the sensor will cause the output pin to toggle. This makes for a robust presence sensor. A reed sensor also works nicely, but can be limited by the glass encapsulation and size. A Hall-Effect sensor is much smaller, but can handle less current...

Reference: RBD-0622

RCWL-0516 Microwave Radar Sensor Module Human Body Induction Switch Module

6 reviews

Transmission signal processing control chip RCWL-9196 Wide operating voltage range 4.0V to 28.0V Penetrating detection capability, compared with the traditional infrared feeling PIR Adjustable Block time and distance Operating Current: 2.8mA (typical); 3mA (max) Detection Distance: 5-9m Transmitting Power: 20mW (typical); 30mW (max) RoboticsBD

Reference: RBD-1201

TFMini S - Micro LiDAR Module

1 review

Measurement range: 12 m. Operating Voltage: 5V. Power : 0.12w. Weight: 6 gm. Compatible with Pixhawk Controller. Frequency: 100Hz

Reference: RBD-0687

Infrared Obstacle Avoidance IR Sensor Module

143 reviews

Detection distance: 2 ~ 30cm Detection angle: 35 ° Comparator chip: LM393 3mm screw holes for easy mounting

Reference: RBD-1205

Slamtec RPLIDAR A1 2D 360 Degree 12 Meters LIDAR Sensor

4 reviews

Distance Range (Radius): 0.15m to 6m, white objects (Diameter Range – 12m) Angular Range: 0 ~ 360º Distance Resolution: < 0.5mm Angular Resolution: <= 1 º Sample Duration: 0.5 ms Sample Frequency: >=8000 Hz Scan Rate: 1 ~ 10Hz, Typical 5.5Hz

Reference: RBD-3552

DYP-L08 Ultrasonic Underwater Obstacle Avoidance Sensor – UART Output, IP68 Rated

The DYP-L08 Ultrasonic Underwater Ranging Sensor is a compact and highly accurate sensor module engineered specifically for underwater applications such as obstacle avoidance, distance measurement, and automatic control. Featuring IP68 waterproofing and the ability to operate reliably at depths of up to 10 meters, this sensor is ideal for submersible...

Reference: RBD-0367

Brand: SparkFun Electronics

LIDAR-Lite v3

1 review

Reliable and powerful ranging and proximity sensor for drone, robot or unmanned vehicle applications Compact, lightweight with low power consumption User-configurable allows adjustment between accuracy, operating range and measurement time Communication via I2C and PWM Requires a power source and an external micro-controller running an application....

Reference: RBD-1206

RPLIDAR A2 360° Laser Range Scanner

Scanning Range: 18M Radius Detection Range:  12M Radius 4cm Ultra-thin Ideal for all kinds of service robot. 8000 times sample rate, the highest in the current economical LIDAR industry 360-degree laser range scanning Low Noise, Brushless Motor New Non-contact Drive OPTMAG Original Design, prolong the life-span Class 1 Laser Safety Standard High-speed...

Reference: RBD-2125

QRE1113 Reflective Optical Sensor

1 review

Phototransistor output  No contact surface sensing  Miniature package

Reference: RBD-2231

CJMCU-3216 AP3216 Digital Optical Proximity Sensor

Working voltage:2.8-3.8V ALS, IR LED and Proximity Detector in an Optical Module; Ambient Light Sensing (ALS); Approximates Human Eye Response; Programmable Interrupt Function with Upper and Lower Threshold; Up to 16-Bit Resolution; High Sensitivity Operates Behind Darkened Glass; Low Lux Performance at 0.01 lux;

Reference: RBD-1204

SHARP Distance Measuring Sensor GP2Y0A710K0F

1 review

Distance measuring range: 100 cm to 550 cm Output type: Analog voltage Output voltage differential over distance range: 2.05 V (typical) Update period: 38 ± 10 ms

Reference: RBD-2848

Magnetic Sensor Door/Window - Reed Switch

Wireless proximity sensor activated magnetically. The device is used mainly to determine the position of doors and windows. Case dimensions - 11 x 16 mm.

Reference: RBD-2183

Digital Auto Counter Meter with Infrared Proximity Sensor 24V

Digital auto counter meter with infrared proximity sensor 24V power supply Adjustable sensing range from 3 to 80 cm Easy to mount chassis Diffuse reflective type light source DC 3-wire NPN-NO output Sensory distance regulator and output LED indicator

Reference: RBD-2543

LPB40B IP65 DToF Single-Point Ranging LiDAR Sensor (0.05-40m, UART)

The LPB40B Single-Point Ranging LiDAR based on the DToF principle. The DToF technology enables the laser radar to work stably under strong outdoor lighting, further improving the stability and accuracy of distance measurement. It is capable of withstanding up to 100klux of ambient light, with a range of up to 40m indoors and outdoors. The overall accuracy...

Reference: RBD-1645

GP2Y0E03 4-50CM Distance Sensor Module Infrared Ranging Sensor Module

Voltage operation: 2.7V-5V Measuring distance: 4 to 50 cm Output: Digital (I/C) / Analog Output Sensor: Infrared LED and CMOS image sensor

Reference: RBD-2836

TCRT 5000 Dual Channel Line Tracking Sensor

1 review

Operating Voltage: 3.5V-5V Supply Current: 15mA Optimal Sensing Distance: 3mm Designed with the reflected infrared sensor, indicator light. Built in a potentiometer for sensitivity control. On-board LM393 voltage comparator chip and infrared sensing probe TCRT5000L Signal detection sensitivity can adjust Reserve all the way more circuits (P3 voltage drawn)
