The 12V DC heavy-duty linear actuator (100mm stroke) is a powerful and reliable solution for various industrial, agricultural, and construction applications requiring long-stroke linear motion. This actuator boasts a maximum force of 900N and a stroke length of 100mm, making it suitable for demanding tasks like pushing, pulling, lifting, and adjusting.
Built to Last:
Engineered for harsh environments, this actuator features a sturdy metal construction for long-lasting durability. Additionally, the IP54 weather resistance rating ensures protection against dust, water, and other external elements. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1. The following conditions can cause serious damage to the product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The following figure shows various parts of the Linear Actuator. Also, please refer to the schematic provided in the attachments for the dimensions of the actuator. Featured By RoboticsBD.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications | |
| Voltage | 12V DC |
| Speed | 10 mm/s |
| Maximum Force | 900N |
| Duty Cycle | 20% |
| Stroke Length | 100mm |
| Total Length | 550mm (retracted) |
| Mounting Type | Fixture H |
| Operating Temp. | -25°C to 65°C |
| Safety Features | Limit switches |
| Weatherproofing | IP54 |
| Shipment Weight | 0.975 kg |
| Shipment Dimensions | 21 x 10 x 6 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 12V DC Long-Stroke Linear Actuator - 100mm
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
If you need actuators in different sizes, we also have those available. Please check the links below.
The latest price of 12V DC Long-Stroke Linear Actuator 100mm in Bangladesh is BDT 5,495 You can buy the 12V DC Long-Stroke Linear Actuator 100mm at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
