The LPD3806-600BM-G5-24C Pulse Solid Shaft Rotary Encoder is a compact and robust incremental photoelectric encoder engineered for accurate position and speed sensing in automation, CNC machinery, and robotics applications. With 600 pulses per revolution and AB phase output, it delivers precise digital feedback for rotational movement. This encoder supports a wide voltage range of 5V to 24V and operates reliably at mechanical speeds up to 5000 RPM. Built from durable polyamide with a 38mm diameter body and 6mm x 13mm shaft, it features a high-speed response of 20K/sec and a compact design for space-constrained installations. The 1.5m integrated cable and clearly labeled wire connections (Green=A, White=B, Red=VCC, Black=GND) simplify setup and wiring. Ideal for use in motor control, automation systems, and measurement equipment. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
High-Resolution Output: Provides 600 pulses per revolution for accurate incremental position feedback.
Wide Voltage Compatibility: Operates on DC 5V to 24V, making it compatible with a variety of systems.
Durable Construction: Compact, polyamide-built 38mm encoder body with solid shaft for long-term reliability.
High-Speed Capability: Supports up to 5000 RPM and 20K/sec electrical response for fast applications.
Color-Coded Wiring: Clearly marked 4-wire connection ensures easy and error-free integration.
Integrated Cable: Includes a 1.5m cable for flexible and extended installations.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
CNC Machines: Use for spindle and axis position tracking in CNC routers and milling machines.
Robotics: Monitor and control joint positions or wheel rotations in robotic systems.
Industrial Automation: Accurate motion feedback in conveyor belts, pick-and-place machines, and sorting systems.
3D Printers and Plotters: Enhance precision in platform positioning and movement synchronization.
Motor Control Systems: Feedback loop for speed and direction control in servo and stepper motor applications.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specifications | |
| Model | LPD3806-600BM-G5-24C |
| Output Type | AB Phase Incremental |
| Pulse Per Revolution | 600 PPR |
| Operating Voltage | DC 5-24V |
| Maximum Mechanical Speed | 5000 RPM |
| Electrical Response Frequency | 20K/sec |
| Integrated Speed | 2000 RPM |
| Shaft Size | 6mm diameter x 13mm length |
| Encoder Body Diameter | 38mm |
| Axis Platform Height | 5mm, 20mm |
| Mounting Hole Type | M3 screw compatible |
| Material | Polyamide |
| Cable Length | 1.5 meters |
| Wire Connection | Green: A, White: B, Red: VCC, Black: GND |
| Shipment Weight | 0.315 kg |
| Shipment Dimensions | 15 x 10 x 5 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x HN3806 Photoelectric Rotary Encoder - 600 P/R, 2-Phase
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of LPD3806-600BM-G5-24C Rotary Encoder - 600 P/R, 2-Phase in Bangladesh is BDT 3,550 You can buy the LPD3806-600BM-G5-24C Rotary Encoder - 600 P/R, 2-Phase at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
