12V 1.8A AC Power Supply with 5.5mm DC Plug Adapter is 2 pin US plug type adapter and 1.1 meters long connecting cable. These adapters are designed to meet all types of power requirements of tablet pc, notebook, and other electronic gadgets. Featured By RoboticsBD.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Features:
- This is a durable product.
- The adapter is easy to use.
- It comes with a long wire.
- Wide input voltage range (100VAC-280VAC).
- Very low no-load power consumption.
- Very low ripple & noise output for device safety.
- Protections against- under-over voltage/ overload/ short circuit with auto-restart on fault removal.
- Thermal shut down (140°C) with auto-restart on cold condition.
- Soft start & low inrush current.
- Isolation up to 3kv for 5sec.time period.
- High operating ambient temperature up to 60°C.
- Highly efficient, compact, durable and long life.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification |
| Brand Name |
Generic |
| Input Voltage (V) |
100 ~ 280 VAC @50 ~ 60Hz |
| Input current (mA) |
100 |
| Output Voltage (V) |
12 |
| Output current (A) |
1.8 |
| Load regulation (%) |
±5 |
| Input Plug |
2-Pin US type |
| Output Plug |
5.5mm DC plug |
| Connecting cable Length (m) |
1.1 |
| Length (mm) |
79 |
| Width (mm) |
52 |
| Height (mm) |
67 |
| Weight (gm) |
120 |
| Shipment Weight |
0.13 kg |
| Shipment Dimensions |
10 × 10 × 6 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
Package Includes:
1 x AC/DC Power Adapter 12V 1.8A
