The 4 DOF Robotic Arm wooden DIY unassembled kit offers a premium quality solution for building your own robotic arm. The kit includes wood cutting parts, screws, and 4 sg90 servos, providing all the necessary components for assembly. With 4 degrees of freedom, this robotic arm offers untrammeled and flexible motion, delivering an unparalleled user experience. Each joint of the mechanical arm is driven by a sg90 servo, ensuring a long service life and convenient use.
The kit is precisely manufactured with high-quality wood material and excellent workmanship, resulting in a lightweight and portable robotic arm. It is an ideal DIY assembly kit for college students, middle school students, DIY enthusiasts, and anyone interested in robotics. Featured By RoboticsBD.
This compact robotic arm features four degrees of freedom, operated through fundamental servo code and electronics. Designed solely for educational purposes, it is not intended for heavy lifting tasks. Do not expect it to carry any weight; its primary aim is to provide hands-on learning experiences in robotic arm axis programming & electronics setup.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
| General Specification | |
| Product Name | 4 DOF Robotic Arm wooden DIY unassembled |
| Material | Wood |
| Servos | 4 sg90 |
| Degrees of Freedom | 4 |
| Shipment Weight | 0.120 kg |
| Shipment Dimensions | 10 x 10 x 6 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x set of wood cutting parts
1 x pack of screws
4 x sg90 servos
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
The latest price of 4 DOF Robotic Arm Wooden DIY Unassembled in Bangladesh is BDT 1,190 You can buy the 4 DOF Robotic Arm Wooden DIY Unassembled at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
