The 37GB-550 12V high torque gear motor is a workhorse for various applications demanding precise control and high power in a compact design. This DC motor features a gear reduction mechanism that reduces its rotational speed (RPM) while significantly increasing its torque output. This makes it ideal for projects requiring controlled movement and the ability to handle heavier loads.
The 37GB motor operates on a voltage range of 12V DC, making it compatible with most common power supplies and battery packs. The motor features a D-type shaft for easy attachment of wheels, gears, or other mechanical components. Its metal body construction ensures durability and long-lasting performance.
Product Images are shown for illustrative purposes only and may differ from the actual product.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
General Specifications | |
Model Number | 37GB-550 |
Voltage | 12V DC (6V-24V operational range) |
Speed | 100 RPM |
Current Draw | 1-5 Amps (depending on load) |
Shaft Type | D-Type |
Body Material | Metal |
Shipment Weight | 0.290 kg |
Shipment Dimensions | 12 x 5 x 5 cm |
Please allow 5% measuring deviation due to manual measurement.
RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD
1 x 37GB 12V High Torque Gear Motor - 100 RPM
