The GP2Y0A51SK0F is a compact and highly responsive infrared distance sensor that combines a position sensitive detector (PSD), an infrared LED, and a signal processing circuit into a single, integrated unit. Utilizing the triangulation method, this sensor offers stable and reliable distance measurements that are minimally affected by environmental factors such as target reflectivity, ambient temperature, or operating time.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
The GP2Y0A51SK0F is a compact and highly responsive infrared distance sensor that combines a position sensitive detector (PSD), an infrared LED, and a signal processing circuit into a single, integrated unit. Utilizing the triangulation method, this sensor offers stable and reliable distance measurements that are minimally affected by environmental factors such as target reflectivity, ambient temperature, or operating time.
Designed to output an analog voltage proportional to the measured distance, the GP2Y0A51SK0F provides quick and accurate proximity detection, making it ideal for robotics, obstacle avoidance, automation systems, and various touchless detection applications. Its short measuring cycle of just 16.5ms enables real-time responsiveness critical for dynamic environments.
Integrated design: Combines PSD, infrared LED, and signal processing in one module
Stable distance measurement: Minimal influence from target color, reflectivity, or ambient conditions
Fast response time: Short measuring cycle of 16.5ms
Analog output: Provides easy-to-use, continuous distance signal
Compact and lightweight: Ideal for embedded and space-constrained applications
Proximity sensing capabilities: Can also function effectively as a proximity sensor
Measuring Method: Triangulation with infrared LED
Detection Distance Range: 2 cm to 15 cm
Output Type: Analog voltage corresponding to distance
Measuring Cycle: 16.5ms
Light Source: Infrared LED
Power Supply: Typically 4.5V to 5.5V (check datasheet for exact details)
Response Time: Fast response suitable for real-time applications
Compact Size: Easy to integrate into robotic or portable designs
Connect the power supply (typically 5V) and ground to the sensor.
Read the analog voltage output using a microcontroller’s ADC (Analog-to-Digital Converter) pin.
Map the analog voltage to a distance value based on the sensor’s output characteristics.
Implement appropriate filtering if needed to stabilize readings in dynamic environments.
Obstacle detection and avoidance in robotics
Touchless control systems
Proximity sensing for interactive devices
Object detection in automated systems
Smart home and industrial automation
Safety and alert systems
1 x GP2Y0A51SK0F Infrared Distance Sensor Module
Reliable and accurate short-range distance sensing
Minimal environmental influence for consistent performance
Fast, real-time responsiveness for moving object detection
Analog output simplifies integration into various control systems
Compact and easy-to-mount design for flexible application
Enhance your projects with reliable proximity and distance sensing using the GP2Y0A51SK0F Infrared Distance Sensor.
Order now and experience fast, accurate, and stable distance measurement in your robotics and automation systems!
The latest price of GP2Y0A51SK0F Infrared Distance Sensor in Bangladesh is BDT 750 You can buy the GP2Y0A51SK0F Infrared Distance Sensor at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
