CD4027B is a single monolithic chip integrated circuit containing two identical complementary-symmetry J-K flip flops. Each flip-flop has provisions for individual J, K, Set, Reset, and Clock input signals. Buffered Q and Q signals are provided as outputs. This input/output arrangement provides for compatible operation with the RCA-CD4013B dual D-type flip-flop. RoboticsBD

The CD4027B is useful in performing control, register, and toggle functions. Logic levels present at the J and K inputs along with internal self-steering control the state of each flip-flop; changes in the flip-flop state are synchronous with the positive-going transition of the clock pulse. Set and reset functions are independent of the clock and are initiated when a high level signal is present at either the Set or Reset input. RoboticsBD

The CD4027B types are supplied in 16-lead hermetic dual-in-line ceramic packages (F3A suffix), 16-lead dual-in-line plastic packages (E suffice), 16-lead small-outline packages (M, M96, MT, and NSR suffixes), and 16-lead thin shrink small-outline packages (PW and PWR suffixes) Featured By RoboticsBD.

Product Images are shown for illustrative purposes only and may differ from the actual product.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Applications:

1. Registers
2. Counters
3. Control circuits

Features:

1. Set-reset capability
2. Static flip-flop operation – retains state indefinitely with clock level either high or low
3. Medium speed operation – 16 MHz (typical) clock toggle rate at 10 V
4. Standardized symmetrical output characteristics • 100% tested for quiescent current at 20 V
5. Maximum input current of 1 μA at 18 V over full package-temperature range; 100 nA at 18 V and 25°C
6. Noise margin (over full package-temperature range): – 1 V at VDD = 5 V – 2 V at VDD = 10 V – 2.5 V at VDD = 15 V
7. 5 V, 10 V, and 15 V parametric ratings
8. Meets all requirements of JEDEC tentative standard No. 138, standard specifications for description of 'B' series CMOS devices

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Please allow 5% measuring deviation due to manual measurement.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

Documentation:

1. Datasheet

Package Includes:

1 x CD4027 JK Flip Flop.

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD RoboticsBD

What is the price of CD4027 JK Flip Flop in Bangladesh?

The latest price of CD4027 JK Flip Flop in Bangladesh is BDT 20 You can buy the CD4027 JK Flip Flop at best price from our RoboticsBD or visit RoboticsBD Office.
