The 4-Channel 6A DC Motor Driver Module is a high-performance motor controller designed for powerful robotics and automation projects. Supporting up to 4 DC motors and delivering a constant 6A current per channel, this driver is ideal for applications requiring precise speed control and reliable torque. With support for PWM speed regulation, and compatibility with 3.3V to 5V logic, it integrates seamlessly with microcontrollers like Arduino, ESP32, and Raspberry Pi.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
Product Description:
The 4-Channel 6A DC Motor Driver Module is a high-performance motor controller designed for powerful robotics and automation projects. Supporting up to 4 DC motors and delivering a constant 6A current per channel, this driver is ideal for applications requiring precise speed control and reliable torque. With support for PWM speed regulation, and compatibility with 3.3V to 5V logic, it integrates seamlessly with microcontrollers like Arduino, ESP32, and Raspberry Pi.
This module is built for reliability, offering stable performance under high loads. When used with proper fan-assisted cooling, it maintains consistent performance without overheating, making it suitable for both hobby and industrial-level robotic platforms.
Key Features:
Drives up to 4 DC motors simultaneously
6A constant current per channel (with fan cooling under high load)
Supports PWM speed control for each channel
Compatible with 3.3V–5V microcontrollers
Operates on 3–12V power supply
Stable and reliable under extended use
Compact square form factor for easy integration
Technical Specifications:
Supply Voltage: 3–12V DC
Logic Control Voltage: 3–5V
Drive Current: 6A continuous per channel
Transient Peak Current (max 5ms): ≤7A
Motor Channels: 4
Module Dimensions: 47 × 47 × 14 mm
Important Notes:
Reverse polarity is not supported – ensure correct power connection
Do not exceed 12V input or 6A per channel
For sustained high current operation, active cooling (fan) is recommended
How to Use:
Connect your DC motors to the designated motor terminals.
Supply power (3–12V) to the module, ensuring correct polarity.
Connect control lines from your microcontroller (3.3V or 5V logic compatible).
Use PWM signals to regulate speed and direction for each motor channel.
Monitor heat buildup and apply fan cooling as necessary for high current operation.
Applications:
Smart robots and RC vehicles
Motorized platforms and chassis
DIY automation projects
Conveyor and wheel control systems
Educational robotic kits and mobile robots
Package Includes:
1 × 4-Channel 6A DC Motor Driver Module
Why Choose This Product?
Engineered for high-load, multi-motor applications, this driver module offers precision control, strong current handling, and microcontroller compatibility in a compact, reliable format. It's the perfect choice for anyone needing robust motor control in demanding environments.
Upgrade your robotics project with this powerful and versatile 6A motor driver—built to handle the toughest tasks with ease!
The latest price of DC Motor Driver Module 4-Channel 6A with PWM Speed Control in Bangladesh is BDT 1,190 You can buy the DC Motor Driver Module 4-Channel 6A with PWM Speed Control at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
