This is an Arduino rotation potentiometer , it is able to rotate up to 300-degree. With the Arduino IO expansion board, in combination, it can be very easy to achieve position-dependent interaction with the rotating effect or produce MIDI instrument. So with this sensor, you can learn how rotary potentiometer works and what analog signal is. You can have much fun with this basic input device.
Store Pickup Available!
Free Ship Over 5000 BDT
Quality Product
No Warranty
No Replacement
Gravity Interface is adapted to allow plug&play. The IO Sensor Expansion Shield is the best match for this sound senor connecting to your Arduino. As this sensor can work at 3.3V which make it compatible with Raspberry Pi, intel edison, joule, and curie.
Improvement List
Rotating this sensor can input different voltage which can change Brightness of this LED.
What is potentiometer?
"A potentiometer is an instrument for measuring the potential (voltage) in a circuit. A fraction of a known voltage from a resistive slide wire is compared with an unknown voltage by means of a galvanometer. The sliding contact or wiper of the potentiometer is adjusted and the galvanometer briefly connected between the sliding contact and the unknown voltage. The deflection of the galvanometer is observed and the sliding tap adjusted until the galvanometer no longer deflects from zero. At that point the galvanometer draws no current from the unknown source, and the magnitude of voltage can be calculated from the position of the sliding contact."
Analog Rotation Potentiometer Sensor V1 For Arduino Related Projects:
Project 2: Power outages anticipation device ready for Maker Faire Rome
Introduction: Edenoff, a TinyML Arduino device was modified for secure and interactive demos at Maker Faire Rome 2022
The latest price of Gravity Analog Rotation Potentiometer Sensor for Arduino - Rotation 300° in Bangladesh is BDT 590 You can buy the Gravity Analog Rotation Potentiometer Sensor for Arduino - Rotation 300° at best price from our RoboticsBD or visit RoboticsBD Office.
|
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. |
|
Product Images are shown for illustrative purposes only and may differ from the actual product. |
